48 Teeth Gear

                SKU: MES-GER-001  |  HSN: 84839000

48 teeth precision machined gear. Hobbed to DIN quality. As per customer drawing.

₹680.00

per unit | + GST 18.00%

Min. Order: 50 pcs | Lead Time: 21 days

Material: EN24 / 20MnCr5 Steel

Tolerance: ±0.02mm

Surface Finish: Hobbed / Heat Treated

48 teeth gear manufactured by hobbing process to DIN 7 quality. Module and pressure angle as per customer drawing. Heat treated for hardness. Profile inspected on gear testing machine. Keyway broached.

No. of Teeth	48
Quality Standard	DIN 7
Process	Hobbing + Shaving
Heat Treatment	Case Hardened 58-62 HRC
Inspection	Gear Testing Machine
